iM3 Veterinary Dental Light

(No reviews yet) Write a Review

Contact +353 (0)1 691 1277 or order via FORM below

SKU:
VDLWM1
  • iM3 Veterinary Dental Light
  • iM3 Veterinary Dental Light
  • iM3 Veterinary Dental Light
  • iM3 Veterinary Dental Light
  • iM3 Veterinary Dental Light
  • iM3 Veterinary Dental Light
€2,135.88

Description

iM3 Veterinary Dental Light

Larger spot for a true veterinary dental light

The iM3 Veterinary Dental Lights use advanced LED technology designed particularly for veterinary dentistry. Unlike human dental lights with small focus areas, our veterinary-specific lights offer a lighted field of 300 x 200 mm at a distance of 1 meter. The larger spot dimension and 35,000 LUX intensity also make the iM3 Veterinary Dental Light versatile for multiple uses.



Field uniformity

Thanks to the exclusive reflected light optical projected through the 258 small reflecting facets of the 2 parables, the iM3 Veterinary Dental Light avoids direct vision of the 2 LEDs from the light source and achieves a uniform lighted field of 300 × 200 mm.



Scialytic effect

One of the main functions of the light is to limit any shadows so that the user can count on an operating area that is clear and uniform. Its configuration is designed to produce a uniformed beam from multiple spots. The scialytic effect of the iM3 Veterinary Dental Light generates an ellipse of only 9 × 6 mm. This reduces the presence of shadows to a minimum.  The term “scialytic” comes from the Greek and stands for “dissolved shadows”.



3D Rotation

Perfect balancing combined with the exclusive 3D rotation system of the head on its optical axis, ensures precise orientation of the light beam greatly reducing glare.





Specifications



Power supply voltage - 24 Vac - 50/60Hz - 24 Vdc

Power consumption - max 9 VA

Lux - from 3,000 to 35,000 (at a distance of 1 m)

Light spot dimension - 300 x 200 mm (at a distance of 1 m)

Cooling system - Static heat sink (no fan required)

Handles - Removable and autoclavable
